CALCOMP-BEFEHLE UND -STIFTE
134 U1 Plot
• Symbols Commands:
font selection
+ [nicht alle Symbole]
symbol string count +
plotter symbol scaling +
controller symbol scaling +
symbol characteristics +
extended characters +
select symbol set 0-4 +
plotting symbol from selected symbol set +
user defined symbol
+
erase user symbol set +
• Circles Commands:
chordal tolerance
+
circle command for circles +
circle command for arcs +
• Dashlines Commands:
dash bypass
+
dashline +
• Additional Commands:
no operation
+
pass through 8 bits direct to plotter
no
operation +
newplot −
manual −
pause
−
operator message −
operator message with pause −
• Defaultwerte der Calcomp-Stifte:
Die derzeit 16 Calcomp-Stifte weisen folgende Defaultwerte in
der Stiftdicke auf:
Stift Stiftdicke in mm Stiftdicke in Pixeln
1 0,06 1
2 0,13 2
3 0,19 3
