IWS + ICS Re:sound I
5
You need to use the supplied fitting
template when doing a standard
installation of the fitted speakers in a
suspended ceiling or wall.
ICS 52 – Installation opening
16
5 m
m
6.5
in
ch
IWS 52 – Installation opening
148 mm
5.83 inch
R
12
m
m
R
0.5
in
ch
Max. wall thickness: 32 mm
Make sure that once the opening has
been cut out, no dirt remains in the
installation opening and that any
movable parts are fixed in place.
ICS 82 – Installation opening
23
8 m
m
9.4
in
ch
IWS 82 – Installation opening
222 mm
8.75 inch
R
12
m
m
R
0.5
in
ch
Max. wall thickness: 32 mm
Installation in suspended ceilings or hollow walls
INSTALLATION - Preparation
