Technical data
Audio data
ICS 52 / IWS 52
ICS 82 / IWS 82
,
Frequency response*:
50 Hz - 20 kHz
32 Hz - 20 kHz (IEC)
Frequency response **:
60 Hz - 20 kHz
48 Hz - 20 kHz (IEC)
Crossover frequency:
4 kHz
3.8 kHz
Load capacity:
50 / 70 Watt
80 / 110 Watt
Impedance:
6 Ohm
6 Ohm
Nominal sound pressure:
88 dB / 2.83V/ 1m
90 dB / 2.83V/ 1m
Rec. amplifier power:
20-100 Watt
20-150 Watt
*
In suspended ceilings
**
In Revox fitted housing
Dimensions
ICS 52
,
ICS 82
,
External diameter
1
:
∅ 202 mm
∅ 277 mm
Build-in diameter:
∅ 164 mm
∅ 238 mm
Dimensions
IWS 52
,
IWS 82
,
Outer dimensions:
172 x 172 mm
250 x 250 mm
Build-in dimensions:
148 x 148 mm
222 x 222 mm
Max. wall thickness:
32 mm
32 mm
Build-in depth:
75 mm
95 mm
Colour:
White
White
Weight :
1.2 kg
2.1 kg
1
incl. installed speaker grill
E & O E
We reserve the right to make technical modifications
