IWS + ICS Re:sound I
6
In the case of a new-build, we
recommend the use of the
corresponding, watertight installation
housing made of gas concrete from
Revox. This is either fitted in the wall at
the building shell phase or fixed to the
boarding when sealing the walls or
ceiling. The build-in housing from
Revox includes all the required parts:
1 x Installation housing
1 x Sound-proofing material
1 x Stopper
Inceiling 52 Installation housing
Part no.: 1.084.481.00
Sealing the fitted housing
The installation housing is fixed to
the boarding with 4 nails at the pre-
drilled positions.
Flush mounting the fitted housing
If the fitted housing is to be flush
mounted in a brick wall, you must
ensure that the plaster coating that is
added later, is flush with the housing.
Inceiling 82 Installation housing
Part no.: 1.084.486.00
410 mm / 16.2 inch
410 mm / 16.2 inch
11
2.
5
m
m
4.
43
in
ch
12
.5
m
m
/
0.
5
in
ch
10
0
m
m
/
16
.2
in
ch
450 mm / 17.8 inch
45
0
m
m
/
17
.8
in
ch
250 mm / 9.85 inch
250 mm / 9.85 inch
11
2.
5
m
m
4.
43
in
ch
12
.5
m
m
/
0.
5
in
ch
25
0
m
m
/
9.
85
in
ch
290 mm / 11.5 inch
29
0
m
m
/
11
.5
in
ch
Installation in the Revox fitted housing – option*
INSTALLATION - Preparation
*
Not suitable for constructions with fair-faced concrete
