INSTALLATION
Info
The Re:sound I inceiling and inwall
speakers have integrated rotary
tensioners to enable quick
installation. These rotary tensioners
are located on the rear of the
speaker and swivel out through 90°
once the 4 marked screws (see
figure on the next page) on the front
of the speaker are screwed in.
Power should be switched off when
installing the speaker.
Installation
Step 1
Connect the speaker cable, with the
correct polarity, using the pluggable
screw connectors.
Step 2
Insert the screw connectors in the
corresponding socket, which is
located on the crossover board of the
speaker.
Step 3
Insert the fitted speaker into the
opening and tighten the 4 rotary
tensioner screws a little, until the
speaker flange is held in position at
the sides. Under no circum-stances
should the speaker flange be twisted.
Revox fitted housing:
Don’t forget the sound proofing
material.
Step 4:
In the last step the magnetic speaker
grill is attached to the speaker.
