Florabest FAH 18 B2 - Handbuch (Seite 22)

22
GB
for damages caused by unspecified use or
incorrect operation.
Before use, check that the blades
are sharp. Ensure that the blades
are sharpened whenever blunt, in
order to avoid overstressing of the
machine. Damages caused by cut-
ting with blunt blades are not cov-
ered by the guarantee.
General Description
See the front fold-out page for
illustrations.
Scope of delivery
Carefully unpack the trimmer and check
that it is complete:
- Cordless hedge trimmer
- Knife guard
- Battery
- Battery charger
- Instruction Manual
Overview
1 Strike guard
2 Safety knife bar
3 Hand protection
4 Safety switch
5 Front handle
6 Ventilation slots
7 On/Off switch
8 Rear handle
9 Battery
10 Battery release buttons
11 Battery charge state indicator
12 Battery charger
13 Knife guard
14 Guide track
15 Button
Function Description
The cordless hedge trimmer features a high-
quality knife made from special lasercut steel.
When trimming, the cutting teeth move to
and fro in a linear shearing motion. The strike
guard at the tip of the knife prevents unpleas-
ant kickback reactions when hitting walls,
fences, etc. Operators are protected by the
appliance’s two-hand safety switch and quick-
stop brake function. The hand protection
guards your hands against twigs and branch-
es. Read the sections below to learn more
about each operating element’s function.
Technical Data
Appliance
Motor voltage ............................ 18 V
Idling speed .................. 1300 min -1 (rpm)
Runtime ............................. max. 50 min*
Cutting length ....................appr. 520 mm
Max. cutting capacity ...........appr. 15 mm
Weight (without battery charger) .....2.7 kg
Sound pressure level
(L
pA
) .................. 77.5 dB(A), K
pA
=3 dB(A)
Sound power level (L
wA
)
guaranteed ........................... 93 dB(A)
measured ...... 91 dB(A); K
wA
=2.09 dB(A)
Vibration (a
n
) .........................................
Rear handle ...... 0.970 m/s 2 , K=1.5 m/s 2
Front handle.......1.964 m/s 2 , K=1.5 m/s 2
Battery (Li-Ion)
Nominal voltage ........................ 18 V
Capacity ..................................... 1.3 Ah
Charging time ...................... approx. 5 h
Recharger .......................JLH082100350G
Nominal consumption .....................12 W
Voltage input ......... 100-240 V~50/60 Hz
Voltage output ...............21 V 350 mA
Protection class ................................ II
Protection category...........................IP20
* The actual runtime under load of a fully charged
battery depends on how you work and on the load put
on the trimmer during operation.
