Specifications
Setup dimensions:
approx. 58 x 84 x 43 cm
Grill:
approx. Ø 39 cm
Weight:
approx. 5.2 kg
Capacity:
approx. 1.5 kg
Required Tools
Phillips screwdriver
Spanner
8 mm
Preparing Assembly
1. Please read the assembly instructions carefully
and follow the safety precautions.
2. Allow sufficient time for assembly.
3. Before starting assembly, clear an area
measuring approximately two to three square
metres.
4. Remove the set from the packaging!
5. Lay out all parts and any necessary tools so that
they are within easy reach.
6. Please use the following list and drawing to
check that all parts are present.
Parts List
Name
Qty.
A: Windbreak
1
B: Cooking grill
1
C: Wooden handles for cooking grill
2
D: Coal grill
1
E: Fire bowl handle
2
F: Fire bowl
1
G: Rear pedestal panel
1
H: Front pedestal panel
1
I:
Ash pan
1
J:
Base
1
K: Ventilation disc
1
