Florabest FAT 18 B2 - Handbuch (Seite 23)

23
GB
Functional description
The.trimming.assembly.of.the.manually.
controlled,.portable,.battery-operated.
lawn.trimmer.consists.of.a.system.of.plastic.
knife/cutting.insert..
The.appliance.also.features.a.pivoting.mo-
tor.head,.adjustable.aluminium.telescopic.
shaft,.and.a.spacer.bow.
A.hood.covering.the.cutting.device.protects.
the.user.
The.following.describes.the.functions.of.the.
operating.parts.
This.equipment.is.not.suitable.for.commer-
cial.use.
Commercial.use.will.invalidate.the.guar-
antee.
Technical data
Appliance
Motor.voltage........................... 18.V .
Idling.speed................8000.min -1 .(rpm)
Protection.Class................................ III
Runtime...........................max..50.min*
Cutting.circle..............................25.cm
Weight.(without.battery.charger).... 2.1.kg
Sound.pressure.level.
(L
pA
)...............71.3.dB(A),.K
pA
=.3.dB(A)
Sound.power.level.(L
wA
)
guaranteed.........................94.dB(A)
measured......89.dB(A);.K
wA
=1.94.dB(A)
Vibration.(a
n
)
upper.handle..1.098.m/s 2 ,.K=1.5.m/s 2
additional.handle
...................... 1.539.m/s 2 ,.K=1.5.m/s 2
Battery.(Li-Ion)
Nominal.voltage....................... 18.V
Capacity...................................1.5.Ah
Charging.time.................... approx..5.h
Recharger............. JLH082100350G
Nominal.consumption.................. 12.W.
General description
Extent of the delivery
Carefully.unpack.the.trimmer.and.check.
that.it.is.complete:
-. Battery-operated.lawn.trimmer
-. Protective.cover.
-. Auxiliary.handle
-. 20.Cutting.inserts
-. Battery.charger
-. Battery
. The.illustrations.are.on.the.front.
fold-out.page.
Overview
. 1. Top.handle
. 2. On/Off.switch
. 3. Switch.lock
. 4. Box.for.cutting.inserts.(not.visible)
. 5. Auxiliary.handle
. 6. Handle.rod
. 7. Lock.of.handle.rod.adjustment
. 8. Threaded.bush.for.length.adjust-
ment
. 9.. Telescopic.shaft
. 10. Motor.head.
. 11. Spacer.bow.(flower.guard)
. 12. Cutting.disk
. 13. Cutting.insert
. 14. Protective.cover
. 15. Bar.for.tilt.angle.adjustment
. 16. Battery
. 17. Battery.release.button
. 18. Battery.charge.state.indicator
. 19. Battery.charger
.20.. Guide.track
.21. Handle.holder
. 22. Handle.screw
.23. Pin
