When.starting.to.charge.and.while.
charging,.the.battery.charge.indicator.
( 19).lights.up.red..
.
When.charging.is.over,.the.light.
changes.to.green.
. 1.. Remove.the.battery.(16).from.the.
appliance,.as.necessary.
.
2.. Inser.the.battery.(16).in.the.
charging.compartment.of.the.bat-
tery.charger.(19)..It.will.audibly.
snap.in..
.
3.. Plug.the.battery.charger.(19).into.
a.mains.outlet..
.
4.. When.the.battery.is.fully.re-
charged.unplug.the.battery.
charger.(19).from.the.mains.
.
5.. Press.the.release.button.( 17).
on.the.battery.(16).and.pull.the.
battery.out.of.the.battery.charger.
(19).
Used batteries
•. If.a.fully.recharged.battery.lasts.for.
considerably.shorter.operating.times,.
the.battery.is.used.up.and.needs.to.be.
replaced..Only.use.an.OEM.battery.
pack.replacement.available.from.our.
Customer.Service.
•. Always.take.heed.of.the.applicable.
safety.instructions.as.well.as.the.envi-
ronmental.protection.regulations.and.
information.(see.“Cleaning.and.Main-
tenance”).
Assembling instructions
. Do.not.insert.the.battery.until.
the.appliance.is.fully.assem-
bled..Risk.of.injury!
. ....To.put.on.the.protective.
cover:
.
1.. Place.the.protective.cover.(14).on.
the.motor.head.(10).and.screw.it.
down.with.the.3.Phillips.screws.
. . To.put.on.the.auxiliary.
handle:
.
2.. Pull.the.ends.of.the.auxiliary.han-
dle.(5).to.extend.the.handle.and.
slide.it.over.the.handle.holder.
(22).
.
3.. Screw.down.the.screw.(23).in.the.
auxiliary.handle.(5).
. . Mounting.the.trimming.unit:
.
4.. Slip.the.cutting.disc.(12).onto.the.
axle..There.is.only.one.mounting.
position..Screw.the.cutting.disc.
(12).to.the.axle..Mind.the.left-
hand.thread.
.
. Place.the.cutting.insert.(13).on.
the.pin.(23).on.the.cutting.disk.
(12).and.pull.out.the.insert.until.it.
snaps.in.
. Spare.cutting.inserts.are.kept.in.the.
box.(4).on.the.auxiliary.handle.(5).
. . To.insert.the.battery:
.
5.. To.insert.the.battery.(16),.place.it.
on.the.guide.track.(20).and.push.
it.into.the.appliance..It.will.audi-
bly.snap.in.
Operation
. Caution:.risk.of.injury!.Do.not.
operate.the.appliance.with-
out.the.protective.cover..To.
operate.the.appliance,.wear.
suitable.clothing,.eye.and.ear.
protection..
.
Prior.to.every.use,.check.that.
the.appliance.is.operative..Do.
