7
GB IE
Summary
1 Upper handle bar
2 Safety catch
3 Starter cord guide
4 Bottom handle
5 Bowden cable
6 Cable clamp
7 Starter handle with starter cord
8 Filler cap
9 Air filter box
10 Air filter (no illustration)
11 Engine cover with ventilation
holes (finger protection)
12 Spark plug connector
13 Spark plug (no illustration)
14 Exhaust guard
15 2 front wheels
16 Steel plate housing
17 Lever for cutting height adjust-
ment
18 2 rear wheels
19 Oil filler cap with dipstick
20 Grass collection box
21 2 quick clamping levers on bot-
tom handle
22 Rear impact protection
23 Grass collection box carrying
handle
24 Fill level indicator
25 2 quick clamping levers on up-
per grip handle
26 Spare spark plug
27 Spark plug wrench
28 Plastic straps catcher
29 Grass catcher rod
30 Grass collection box suspension
bracket
31 Filler plugs
32 Bar slot
33 Cut height position
Functional Description
The equipment is driven by a powerful
four-stroke engine (Briggs & Stratton 450 E
Series).
The device is equipped with a high quality
steel plate housing, a grass catcher and a
foldable grip handle.
Refer to the following descriptions for a
functional description of the controls.
Safety Equipment
2 Safety catch
The equipment stops when the
safety catch is released.
14 Exhaust guard
prevents hands or combustible
materials from coming into con-
tact with a hot exhaust.
22 Rear and side impact pro-
tection
protect the operator from parts
that are flung out and from ac-
cidentally touching the blades
when mowing with no grass col-
lection box.
