English - 19
The dual-band wifi range extender then automatically connects to your wireless
router and copies all of the settings. Once the connection has been successfully
established, the 2.4G signal LED (1) or the 5G signal LED (2) lights up. The
dual-band wifi range extender can then be used. The dual-band wifi range
extender can be accessed via the SSID and the network key of your wireless
router.
You can then use the dual-band wifi range extender where the wireless signal
is to be extended. The optimal location for the dual-band wifi range extender is
exactly in the middle between your wireless router and the wireless devices
which are to be connected to the network using the dual-band wifi range
extender. Test other locations if the dual-band wifi range extender does not
work there. Insert the dual-band wifi range extender only into a socket that is
always easily accessible.
It is possible to configure multiple dual-band wifi range
extenders. These should be configured one after the other.
If your wireless router does not support WPS or the connection fails for some
other reason, you must manually configure the dual-band wifi range extender.
