42 - English
If the dual-band wifi range extender was previously used in
another network, it might not be accessible any longer at the
default address. In this case, the dual-band wifi range extender
must be reset. See the second point for "The configuration menu
of the dual-band wifi range extender is not shown" in the
"Troubleshooting" section.
1. You can establish the connection via a network cable or via a wireless
network. If you want to establish the connection via a network cable, you
have to connect the dual-band wifi range extender to your computer. Use
the network cable included with the device for this purpose. Insert one end
of the network cable into the LAN socket (8) of the dual-band wifi range
extender and the other end into the LAN socket of your computer.
2. Alternatively, you can establish the connection via the wireless network. To
do so, start the search for available wireless networks on your computer.
The network WiFi Repeater(2.4G) or WiFi Repeater(5G) is
displayed in the list of available wireless networks. Select the network
WiFi Repeater(2.4G) or WiFi Repeater(5G) and click on the
Connect button to connect wirelessly with the dual-band wifi range
extender. After having pressed the Connect button, you may have to
click the option Connect without configuring the network.
After you have established the connection as previously described, open the
Internet browser on your computer. Enter http://192.168.10.1 in the
address line of the Internet browser and confirm the entry with the Enter
button.
