14 GB/IE
Mounting / Start-up Mounting
Note: The recommended installation height is be-
tween 1.8 and 2.5 m.
Note: Before installation, ensure an optimal direc-
tion of motion. The motion detector reacts more
sensitively to movement from the side than to motion
from the front (see Ill. A). Therefore, we recommend
installing the motion detector
1 to the side of the
direction of movement.
Note: To attach the base plate
2 it is necessary
to drill two holes. We recommend a drill with a
6 mm diameter.
Remove the screws 4 from the front of the motion
detector by screwing them in the direction of
rotation (see Ill. B).
Insert the cable through the cable opening of the
base plate
2 .
Screw the base plate 2 to the desired position.
Connect the cable to the screw terminal 3 of the
motion detector as depicted in Ill. C.
