iStorage 1TB diskAshur PRO2 USB 3.1 Encrypted Portable HDD - Handbuch (Seite 10)

#10
iStorage diskAshur PRO
2
®
Manual – v 3.0
www.istorage-uk.com
10. Set Read-Only in Admin Mode
When Admin writes content to the diskAshur PRO 2 and restricts access to read-only, the User cannot change this setting in
User mode. To set the diskAshur PRO 2 to Read-Only, first enter the “ Admin Mode ” as described in section 5. Once the drive
is in Admin Mode (solid BLUE LED) proceed with the following steps.
1. In Admin mode, press and hold down “ 7 + 6 ”
buttons. (7= R ead + 6= O nly)
Solid BLUE LED will change to blinking GREEN
and BLUE LEDs
2. Release 7+6 buttons and press “ UNLOCK ”
GREEN and BLUE LEDs will change to a solid
GREEN LED and then to a solid BLUE LED
indicating the drive is configured as Read-Only
11. Enable Read/Write in Admin Mode
To set the diskAshur PRO 2 to Read/Write, first enter the “ Admin Mode ” as described in section 5. Once the drive is in
Admin Mode (solid BLUE LED) proceed with the following steps.
1. In Admin mode, press and hold down “ 7 + 9 ”
buttons. (7= R ead + 9= W rite)
Solid BLUE LED will change to blinking GREEN
and BLUE LEDs
2. Release 7+9 buttons and press “ UNLOCK ”
GREEN and BLUE LEDs change to a solid
GREEN LED then to a solid BLUE LED
indicating the drive is configured as Read/Write
12. How to create a Self-Destruct PIN
The self-destruct feature allows you to set a PIN which can be used to perform a crypto-erase on the entire drive.
When used, the self-destruct PIN will delete ALL data, Admin/User PINs and then unlock the drive. Activating this
feature will cause the Self-Destruct PIN to become the new User PIN and the diskAshur PRO 2 will need to be partitioned
and formatted before any new data can be added to the drive.
To set the Self-Destruct PIN, first enter the “ Admin Mode ” as described in section 5. Once the drive is in Admin Mode
(solid BLUE LED) proceed with the following steps.
1. In Admin mode, press and hold down
“ UNLOCK + 6 ” buttons
Solid BLUE LED will change to blinking GREEN
and solid BLUE LEDs
2. Create a 7-15 digit Self-Destruct PIN and press the
“ UNLOCK ” button
Blinking GREEN and solid BLUE LEDs will
switch to a single GREEN LED blink and then
back to blinking GREEN and solid BLUE LEDs
3. Re-enter the PIN and press the “ UNLOCK ” button
GREEN LED will rapidly blink for several
seconds and then changes to a solid BLUE LED
to indicate the Self-Destruct PIN has been
successfully configured
Important : If data has just been copied to the diskAshur PRO 2 , make sure to properly disconnect the drive
first by clicking ‘Safely Remove Hardware/Eject’ the diskAshur PRO 2 from the Operating System before
reconnecting and setting the diskAshur PRO 2 as ‘Read-Only/Write-Protect’.
