Step 7
♦ Secure the wooden grip onto the rear part of the skewer (straight edge)
with light hammer blows. Slide the barbecue racks onto the skewer.
Secure the barbecue racks with the eye screws M4x10.
♦ Hook the two handles onto the cooking grill 5 .
Step 8
♦ Place the cooking grill 5 and the skewer inside the wind shields 2 3 4 .
You can now remove the handles from the cooking grille 5 so that they do
not interfere when you are barbecuing.
♦ To fi nish the assembly, tighten all screw connections fi rmly.
5
5
2
3 4
