6 GB/IE
Sink Mixer Tap
 Introduction
Dear Customer, you have purchased a durable
high quality product manufactured by us. Before
installation please read through the whole of these
instructions and take note of the advice they contain
before you start the installation. These instructions
contain important information about installation,
settings and care. Keep these instructions safe and
if you pass on the product to anyone else please
pass on the documentation as well.
 Proper use
This product is suitable for instantaneous water
heaters (flow heaters) and boilers. It is not suitable
for low pressure water heaters such as wood or
coal burning bath geysers, oil or gas bath geysers,
open electrically heated water tanks. Any use other
than that described here or modification to the prod-
uct is not permitted and may lead to damage to
persons or property. There is also the risk of injury
and loss of life. The product is intended for person-
al use only and not for medical or commercial use.
 Components, fittings
and fixings
1 Adjusting lever / handle
2 Locking screw
3 Hot / cold plate
4 Cartridge cover ring
5 Cartridge sealing ring
6 Adjusting ring
7 Cartridge
8 Guide for eccentric rods
9 Faucet body
10 Mixer nozzle
11 Sealing ring
12 Crescent-shaped seal
13 Crescent-shaped metal disc
14 Setscrews
14 a Hole for set screw
14 b Hole for set screw
15 Nuts
16 Connecting pipes
16 a Hole marked red / hot water connection
16 b Hole marked blue / cold water connection
17 Protective cap
18 Waste plug
19 Plug holder
20 Foam seal
21 Plastic seal
22 Waste fitting block
23 Cone seal for waste fitting
24 Rod with ball
25 Union nut
26 Metal clip
27 Coupling
28 Pull rod / bottom part
29 Pull rod / top part
30 Allen key (for detaching the locking screw 2 )
31 Lever arm
32 Adjustment screw
 Technical Data
Connections: 3 /
8
” IG
Union nut for the
water connection: 19 mm
Water temperature: max. 85 °C
Water pressure:
min.: 0.5 bar,
max.: 3 bar
Safety advice

DANGER OF LOSS OF LIFE
AND ACCIDENT TO INFANTS
AND CHILDREN!
Never leave
children unsupervised with the packaging ma-
terials. Danger of suffocation.
 CAUTION! DANGER OF INJURY! Please
ensure that no parts are damaged and that all
parts are correctly assembled. Incorrect assem-
bly or fitting may lead to injury. Damaged parts
can adversely affect safety and proper function.
