completely, but simply loosen it until the handle
1 can be easily removed.
3. Remove the handle 1 .
4. Unscrew the cartridge end ring 4 . Now pull
the red adjusting ring 6 upwards with the
help of a screwdriver.
Note: Press the cartridge pins slightly back-
wards. This makes it easier to pull up the ad-
justing ring
6 . Do not use pliers. Do not re-
lease the cartridge 7 nut and do not take off
the cartridge.
5. Reducing the hot water flow rate:
Replace the setting ring 6 as shown in Figure
G/1 in offset position.
Restricting the hot water flow rate
completely:
Install the setting ring 6 as
shown in Figure G/2.
Deactivating the hot water flow rate
limitation:
Install the setting ring 6 as
shown in Figure G/3, neutral position.
6. After setting the scald protection device, re-
place the cartridge cover ring 4 and the han-
dle 1 .
 Care and maintenance
 Maintaining and cleaning the
faucet
Please note that sanitary fittings require special care.
Please observe the following instructions:

Dry your fittings with a cloth after each use to
prevent any build-up of lime deposits.

Clean your fittings with clean water, mild deter-
gent and a soft cloth or leather only.

Do not use any agents to remove limescale,
acidic cleaning agents or scouring agents of
any kind. Do not use corrosive or alcohol-con-
taining agents for cleaning (including for col-
oured surfaces).

Screw out the aerator 10 at regular intervals
and remove lime deposits and any foreign bodies.
Replace the aerator with a new one if it is very
heavily contaminated or damaged. A new aera-
tor
10 can be ordered from the service centre in-
dicated.
Note: In normal circumstances the aerator 10
can be unscrewed by hand. If this is not the
case, use a 23 mm spanner and wrap the
aerator in a thin, damp cloth, so that it is not
damaged. You can also use a pipe wrench
with plastic jaws. Take care not to damage the
aerator
10 .
If the care and maintenance instructions are not fol-
lowed, damage to the surface of the fitting can be
expected. Claims under the warranty are excluded
in this case.
 Replacing the cartridge
A cartridge 7 is a wear part that needs replacing
according to the hardness and / or degree of con-
tamination of the water. This becomes evident
when the handle
1 becomes difficult to move.
New cartridges 7 can be obtained from the
listed service office.
Proceed as follows to replace the cartridge 7 :
1. Shut the main water supply off. Al-
low the remaining water to run off.
2. Remove the hot / cold plate 3 and unscrew
the locking screw 2 with the Allen key 30 in
an anticlockwise direction.
3. Pull the handle 1 upwards and off.
4. Unscrew the cartridge cover ring 4 .
5. Release the cartridge securing ring 5 beneath
it with a size 32 spanner and pull the complete
cartridge
7 out of the body 9 of the faucet.
6. Place the new cartridge 7 into the body 9 of
the faucet in exactly the same way. Make sure
that the seal is fitted properly under the cartridge
7 . Make sure that the guides are in the corre-
sponding holes.
7. Replace all aforementioned parts. Tighten the
cartridge securing ring 5 hand-tight whilst
holding the faucet in place against the rotating
movement. This ensures tightness and prevents
the lever motion from becoming sluggish.
