Summary
1 Drive catch
2 Upper handle bar
3 Safety catch
4a Bowden cable lock nut
4b Bowden cable adjusting nut
5 2 lower bars
6 Cable clamp
7 Rear impact protection
8 Bowden cables
9 Oil filler cap with dipstick
10 Exhaust guard
11 Filler cap
12 Engine cover with ventilation
holes (finger protection)
13 Air filter box
14 Air filter (no illustration)
15 Spark plug connector
16 Spark plug (no illustration)
17 2 front wheels
18 Sheet steel housing
19 2 screws and 2 wing nuts for the
lower bar fastening
20 Lever for cutting height adjust-
ment
21 2 rear wheels
22 Grass collection box
23 Grass collection box carrying
handle
23a 2 cross-head screws for the as-
sembly of carrying handle (not
visible)
24 Fill level indicator
25 Starter handle with starter cord
26 Starter cord guide
27 2 screws and 2 wing nuts for the
upper bar fastening
28 Mulch kit (already mounted)
28a Button on the mulch kit
29 Spark plug wrench
30 Petrol can
31 Spare spark plug
32 Bar slot
33 Hard shell grass catcher
34 Catcher net grass catcher
35 Plastic straps catcher
36 Tubular frame grass catcher
37 Grass collection box suspension
bracket
38 Cut height position
39 Garden hose connection
Functional Description
The equipment is driven by a powerful
four-stroke engine (Briggs & Stratton 575
EX Series). The Ready-Start-System, the ball
bearing mounted wheels, the rear wheel
drive and the blade braking function make
the equipment easier to operate. The equip-
ment is fitted with a high quality sheet steel
housing and collapsible handle bar.
There are two modes of operation available
to the user: mowing with the grass collection
box or mulch mowing.
Refer to the following descriptions for a
functional description of the controls.
Safety Equipment
3 Safety catch
The equipment stops when the
safety catch is released.
7 Rear and side impact pro-
tection
protect the operator from parts
that are flung out and from ac-
cidentally touching the blades
when mowing with no grass col-
lection box.
10 Exhaust guard
prevents hands or combustible
materials from coming into con-
tact with a hot exhaust.
