Florabest FBM 575 B1 - Handbuch (Seite 43)

43
GB
Replacement parts/Accessories
Spare parts and accessories can be obtained at
www.grizzly-service.eu
If you do not have internet access, please contact the Service Centre (see “Sercice-Center”
page 46). Please have the order number mentioned below ready.
Pos. Pos. Description Order No.
Instruction Exploded
Manual Drawing
1/2/3 S-01 Upper handle bar/Upper handle bar cover
Drive catch/Safety catch 91102680
5 6 Lower bar 91102696
8 12 Bowden cables 91102688
14 B&S air filter 91102694
17 S-06 Front wheel 91102685
19/27 S-02 Screw set (screw/Wing nut) 91102681
21 S-07 Rear wheel 91102686
22/23 S-03 Grass collection box 91102682
28 S-04 Mulch kit 91102683
31 Spare spark plug 91102697
21 Spring for gear drive 91102691
72 V-belt wheel drive 91102693
S-05 Blade/Blade support/Blade screw 91102684
B&S fuel stabiliser, 125 ml 30230028
B&S engine oil, 600 ml 30230029
B&S Maintenance set (air filter, 30 ml fuel
stabiliser, 600 ml engine oil, spark plug) 91102695
Replacement parts and accessories for the engine (e.g. air filters and spark plugs) can
also be ordered directly from Briggs & Stratton.
If further spare parts should be necessary, please find the part number on the exploded
drawing.
