Technical data
Technical data
1) Optional
2) Pre-fabricated cables
Rated current 200 A
Rated short circuit current 38 kA (250 A gG back-up fuse)
Ambient temperature range -25 - +45 °C
Grid topology TN (universal: TN-C, TN-S and TT grids)
AC overvoltage protection
1)
Type 1+2+3 incl. 80 A back-up fuse
AC input/output 3PN 400/230V
Frequency 50 Hz/60 Hz
AC inputs 2 - 6 x max. 20 kVA/input,
fused 3P 50A NH000 (Fronius Symo)
fused 3P 63A NH000 (Fronius Eco)
Max. output power 120 kVA
Dimensions (height x width x depth) 750 x 700 x 300 mm
Weight (without cables) 38.5 kg
Housing Open air wall-mounted housing
ALU 99.5HH powder coated
Protection class IP 54
AC connection
1) 2)
H07RN-F 5G10mm² (Fronius Symo)
E-YY-O/J 5G16mm² (Fronius Eco)
Data communication connection 1) 2) Patch cable, 2 m, shielded, RJ45,
UV-resistant
Service socket 1) 1PN 230 V/16 A/30 mA, CEE
Compliance with standards EN 61439-2
