56
Scope of Supply - 1 Fronius String Control 100/12
- 2 M32 metric screw joints including counter nuts
- 24 M16 metric screw joints including counter nuts
- 10 M16 threaded plugs
- 1 M20 metric screw joint including counter nut
- 1 M20 metric threaded plug
- 1 M25 metric screw joint including counter nut
- 1 rubber insert
- 1 plastic bolt
- 1 silicone tube Ø 25 x 510 mm (for data communication cable)
- 1 silicone tube Ø 14 x 420 mm (for external power supply)
- 1 fire prevention leaflet
- 2 connection distributors including assembly accessories (for connection to inverter –
see inverter operating instructions)
- 1 leaflet
Optional If type 1 or type 2 overvoltage protection is desired, it can be installed in the Fronius String
Control 100/12 on the DIN rail provided for this purpose.
Technical data
*) applies for single and multi-core cables:
10 mm² with maximum cable diameter of 7 mm
Max. input voltage in no-load operation 600 V
Max. input current 100 A
Max. input current per fuse holder 20 A
Max. number of strings (with integrated solar module fuse) 12
Max. cable cross section for terminals on the solar module side 10 mm² *)
Max. cable cross section for the M12 connections on the invert-
er side 95 mm²
Number of measuring channels 2
Max. current per measuring channel 50 A
Screw joint for cable attachment to the solar module side M16
Screw joint for cable attachment to the inverter side M32
Degree of protection IP 55
Ambient conditions -25 °C - +60 °C
-13 °F - +140 °F
Dimensions (without screw joints) 440 x 358 x 145 mm
17.32 x 14.09 x 5.71 in.
DATCOM power supply via Solar Net
optional via a 12 V power supply
Max. Solar Net current consumption 110 mA
Weight 5 kg
11.02 lbs.
