75
EN-US
Configuration ex-
ample
(1)
Inverter with Fronius Com Card
(2)
Fronius String Control 100/12
(3)
Fronius Datalogger
(4)
Termination plug
Safety
Line/ISDN
OUT
IN
OUT
IN
(1)
(2)
(3)
(4)
(4)
OUT
IN
IN
1
+12V
2
GND
3
Tx-
4
Rx-
5
Rx+
6
Tx+
7
GND
8
+12V
OUT 1
+12V
2
GND
3
Rx-
4
Tx-
5
Tx+
6
Rx+
7
GND
8
+12V
IN
1
+12V
2
GND
3
Tx-
4
Rx-
5
Rx+
6
Tx+
7
GND
8
+12V
OUT 1
+12V
2
GND
3
Rx-
4
Tx-
5
Tx+
6
Rx+
7
GND
8
+12V
IN
1
+12V
2
GND
3
Tx-
4
Rx-
5
Rx+
6
Tx+
7
GND
8
+12V
OUT 1
+12V
2
GND
3
Rx-
4
Tx-
5
Tx+
6
Rx+
7
GND
8
+12V
WARNING! An electric shock can be fatal. Danger from DC voltage from solar
modules.
-
Make sure that the input and output sides in front of the device are not
charged before connecting anything.
-
Any and all connections should only be carried out by qualified electricians.
-
Follow the safety rules in these operating instructions.
