HEIDENHAIN TNC 335 Technical Manual - Handbuch (Seite 88)

3-66
TNC 360 14 Anschlußmaße 3/95
14.5 Einbau-Handräder
14.5.1 HR 130
DIA .3937–.
0004"
DIA .3937–.0008" Ø10
–0.01
Ø10–0.02
Ø36 f8
DIA 1.4173–.
0010"
DIA 1.4173–.0025"
DIA 2.283"
Ø58
1.417–.06"
36–1.5
.551"
14
.492"
12.5
DIA .173“
Ø4.4
120
°
3 x 120
°
30
°
48
1.890"
16
.630"
FIXING HOLE M3 x .197"
Befestigungsgewinde M3 x 5 Ø0.2
DIA .008"
3x
19.5+1
.768+.04"
10
.394"
