3-84
TNC 407/TNC 415/TNC 425 16 Anschlußmaße 11.97
16.7 Handräder
16.7.1 Einbau-Handrad HR 130
DIA .3937–.
0004"
DIA .3937–.0008" Ø10
–0.01
Ø10–0.02
Ø36 f8
DIA 1.4173–.
0010"
DIA 1.4173–.0025"
DIA 2.283"
Ø58
1.417–.06"
36–1.5
.551"
14
.492"
12.5
DIA .173“
Ø4.4
120
°
3 x 120
°
30
°
48
1.890"
16
.630"
FIXING HOLE M3 x .197"
Befestigungsgewinde M3 x 5 Ø0.2
DIA .008"
3x
19.5+1
.768+.04"
10
.394"
